3D-Cut


Femoral Head Reduction Osteotomy: Three Guides, One Shared Reference
A femoral head reduction osteotomy cuts the proximal femur into several pieces and puts them back in a new position. Three patient-specific guides slide over the same two parallel K-wires, so every step shares one reference, from the first cut to the pre-drilling of the fixation screws.
Oct 19


A Sacral Tumor Resection: Breaking the Bone Where a Saw Blade Can't Reach
Through a posterior approach, part of the endopelvic surface of the sacrum lies beyond the reach of a saw blade. In this partial sacrectomy, planned on six cutting planes close to the S1 nerve roots, K-wires guided the osteotomy where the saw could not follow.
Sep 30


Femoral Allograft Reconstruction: Verifying the Fit Before the Graft Reaches the OR
Resecting a bone tumor is only half the job when reconstruction follows. This case shows how patient-specific guides for the resection and the allograft share the same cutting geometry, and how a digital check on the graft caught a poor fit before it ever reached the operating room.
Sep 16


A Variable-Margin Scapula Resection: Clearing the Tumor While Preserving the Coracoid
A partial scapula resection close to the acromion and coracoid process raises a question beyond the tumor itself: how much margin can be taken without compromising the bone segments the shoulder still needs to function. This case used a variable margin, 5 mm along the coracoid side, 10 mm along the two inferior planes, and a cutting guide shaped as a hook around the acromion to guide the resection precisely.
Aug 6


Patient-Specific Guide for Corrective Osteotomy: Closing an Angle and a Rotation in One Move
A cubitus valgus deformity rarely comes down to a single angle. This case combined a 20° medial closing correction with a 12° derotation, using a patient-specific guide system built around four K-wires that align only once both corrections are achieved together — closing an angle and a rotation in one motion.
Jul 30


Periacetabular Chondrosarcoma: Why the First Resection Is the Only One That Counts
For grade 2 chondrosarcoma, the surgical margin is the only oncological defense — chemotherapy and radiation offer no safety net. In this periacetabular case spanning the acetabular and pubic regions, a single patient-specific guide was built in two connected parts to execute three cutting planes with a 10 mm margin in one pass.
Jul 28


Distal Tibia Tumor Resection: Two Guides Built as Geometric Counterparts
Discover how two patient-specific surgical guides were designed as geometric counterparts to achieve accurate distal tibia tumor resection and anatomical allograft reconstruction in a case led by Prof. François Sirveaux.
Jul 9


Femoral Neck Osteotomy: A Four-Guide System and What One of Them Taught Us
A femoral neck osteotomy performed by Dr. Wudbhav Sankar at Children's Hospital of Philadelphia, guided by four patient-specific instruments. Three deployed intraoperatively and one that couldn't be, revealing as much about 3D surgical planning as those that were.
Jun 24


Pelvic Tumor Resection: Why Two Patient-Specific Guides
The tumor combined a bony component with an overlying soft tissue mass. Whether that mass could be displaced enough to fit a single large guide beneath it could not be predicted with certainty. The answer: two distinct guides, one lateral, one posterior, connected by a chevron geometry anchored on the sciatic notch
Jun 11
Explore surgical cases and insights that highlight the role of 3D planning and patient-specific solutions in modern surgery.
